Publish time 2014-10-13 13:56
System Features & Benefits
7.0'' color touch screen
“Plug & play” system
Multi-preset treatment protocols
User friendly and reliable
No air compressor,low maintenance cost
Easy of use

  Technical Principle

The hand piece contains a projectile that is accelerated through the electromagnetic transfer of kinetic energy. This kinetic energy is the transformed into impact energy in the applicator head. The impact energy delivered from the applicator head results in radial pulses in the target tissue.


 7.0'' Color Touch Screen
 Plug & play” system
 Multi-preset treatment protocols
 User friendly and reliable
 No air compressor,low maintenance cost
 Easy of use


• Physiotherapy
• Rehabilitation
• Orthopedics
• Sports medicine
• Aesthetic medicine
• Treatment for urological pain therapy and erectile dysfunction


  Technical Specifications
Power Levels/Energy                        10-185mj (equivalent to 0.1-5bar)
Frequency                                          1-22HZ
Modes                                                4 burst modes(continuous/4/8/12 shocks)
Programmes                                      7 present programmes, adjustable
Protocols                                            More than 25 illustrated preset treatment recommendations
Controls                                             Colour touch-screen fr all software operations
Applicatiors                                       6/15/25mm(35mm as option )
Life Time                                           Minimum 4,000,000 shocks per handpiece, 300,000 shocks per head
Dimensions                                       290x240x130mm(L/W/H)
Weight                                               2.07kg (controller unit only)
Warranty                                            3 years for controller unit, 1 year for accessories
